The SFP-3GM transceivers are fully compliant with the latest industrial SFP Multi-Source Agreement (MSA). They support Serial Digital Interface (SDI) bitrates from 270M to 2,97G in accordance with the standards described by the Society of Motion Picture and Television Engineers (SMPTE).
Digital diagnostics functions according to SFF-8472 allows real-time access to parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
The transceivers operate bi-directionally on single fiber at wavelengths of 1310 nm and 1490 nm. The modules are hot pluggable and can transmit on up to 20 km of SM fiber.
APPLICATIONS
• SMPTE 259M / SD-SDI (270/360Mbit/s)
• SMPTE 292M / HD-SDI (1.485Gbit/s)
• SMPTE 424M / 3G-SDI (2.970Gbit/s)
FEATURES
• Up to 20 km transmission on SM fiber
• 1310 nm / 1490 nm operation
• Hot-Pluggable SFP footprint
• Optical LC interface for bi-directional operation
• Operating temperature 0 °C to 70 °C
