GTP-805A PoE GigEthernet Media Converter

SFP Port, 52V/30W PoE Power

Varenr: MC-PLANET-GTP-805A
Alt. varenr: GTP-805A
Datablad / mer produktinformasjon
BeskrivelseTeknisk infoTilbehør
Beskrivelse
FEATURES
  • 1-Port RJ-45 interface (Data + Power output)

  • 1-Port Fiber Optic SFP Port

  • DC 52V power input socket

  • Powersupply included



  • Complies with IEEE 802.3af standard and IEEE 802.3at standard, Mid-Span PSE

  • Provides DC 52V power over RJ-45 Ethernet cable to devices with Ethernet port

  • Supports PoE Power up to 30 watts for PoE port

  • Auto detects of IEEE 802.3at / IEEE 802.3af PoE equipment protecting the devices from being damaged by incorrect installation

  • Remote power feeding up to 100m

  • IEEE 802.3at / IEEE 802.3af splitter devices compatiblility



  • Metal Case

  • LED indicators:
    - Power LED
    - PoE In-use
    - Fiber LNK / ACT
    - TP LNK / ACT

  • DIP-switch: LFP (Link Fault Pass-through) Mode selection

  • Standard Compliance:
    • IEEE 802.3 10Base-T
    • IEEE 802.3u 100Base-TX
    • IEEE 802.3ab 1000Base-T
    • IEEE 802.3z 1000Base-X
    • IEEE 802.3af Power over Ethernet Standard
    • IEEE 802.3at Power over Ethernet enhancements Standard
    • FCC Part 15 Class A, CE


Teknisk info

Produktinformasjon

Bruksområde Konvertering av bitrate
Protokoll / bitrate Gigabit Ethernet
Fiberport SFP/SFP+
Kobberport Ja, RJ45
Power over Ethernet (PoE) Ja, PoE output
Management Nei
Kan plasseres i chassis Nei
For DIN-skinne Nei
