P20-144MS-LCA-PIG-20 Fiberworks AS Panel preterm 2U G144 QXAI LCA-PIG 20 m LC/APC i 2U panel, åpen ende B
Panel preterm 2U G144 QXAI LCA-PIG 20 m LC/APC i 2U panel, åpen ende B

Panel preterm 2U G144 QXAI LCA-PIG 20 m

LC/APC i 2U panel, åpen ende B

Varenr: P20-144MS-LCA-PIG-20
Vis varianter som liste
Datablad / mer produktinformasjon
BeskrivelseTeknisk infoAlternativer
Beskrivelse

Preterminert patch panel 2U (FP20) 144x LC/APC-Åpen, QXAI (QXXI) Micro sheath kabel

Fiberworks leverer en serie universelle preterminerte patch panel produsert i aluminium med høy funksjonalitet for terminering og skjøting i 19” og ETSI-rack. Panelene er tilgjengelig i 1,5U og 2U, og er dybdejusterbare. De består av en base med en uttrekksskuff og utskiftbare adapterplater. Den fleksible konstruksjonen gir et brukervennlig arbeidsmiljø ved behov for oppgraderinger, endringer eller utvidelser. Panelene kan enkelt konverteres til ETSI-standard ved å snu monteringsbrakettene.

KARAKTERISTIKA:

  • Kabel ende A: Leveres med 1,8 meter fan-out innmontert i panel. Lengden kommer i tillegg til bestilt lengde.
  • Konnektor ende A: LC/APC
  • Kabel ende B: Leveres uterminert
  • Konnektor og adapter møter IEC 61754-20
  • Patch panel: 2U Aluminium, Hvit RAL 9010.
  • Kabel: QXAI (QXXI) Microsheath (løs kledning), LSZH, gul, CPR: Dca s2d2a1
  • Fibertype: Singelmodus ITU-T G.652.D/G.657.A1 (MFD 9,2µm @1310nm), EN 50173-1 OS2
  • Kvalitet: IEC 61753-1 klasse C1
  • Instikkstap: Maks/typ.: <0,30/<0,18dB
  • Reflektert effekt.: Maks/typ.: -60/-63dB
  • Kan benyttes i CWDM/DWDM/PON nett
  • Kan monteres i 19" og ETSI skap/rack
  • Telenor fargekode

MERK! Mot en kostnad kan kabelen leveres på trommel. Gi beskjed om dette ønskes

Teknisk info

Produktinformasjon

Formfaktor 19" 2U
Fiberantall G144
Fibertype Singelmodus G.657.A1
Konnektortype Vinklet (APC)
Sliping APC - åpen (vinklet - åpen)
Farge Gul
Konnektor LC/APC
