The OSFP FR4 transceiver is a 400 Gbit/s pluggable module for optical data communications such as 400GBASE Ethernet and NDR InfiniBand. The transceiver operates with four parallel data streams of 106,25 Gbps in order to provide an aggregated signaling rate of 425 Gbps. The module has a duplex LC connector. The four lanes are launched with center wavelengths of 1271 nm, 1291 nm, 1311 nm and 1331 nm and multiplexed onto single mode fiber. On the receive side, the four lanes of optical data streams are de-multiplexed by the transceiver and retimed.
The module is fully compliant with all OSFP related MSA standards and Digital Diagnostic functions are available through an I2C interface. OSFP-FR4 complies with IEEE 802.3, 400Gbase-FR4 and NDR InfiniBand.
APPLICATIONS
• 400G Ethernet
• 4x100G Ethernet
• NDR InfiniBand
• Data Center and LAN
FEATURES
• Compliant with 400Gbase-FR4
• Compliant with NDR InfiniBand
• 4 CWDM lanes Mux/Demux design (1271, 1291, 1311 and 1331 nm)
• Up to 106.25 Gbps Data rate per wavelength
• Up to 2km transmission on SMF (with FEC)
• Electrically hot-pluggable
• Digital Diagnostics Monitoring Interface
• Compliant with OSFP Flat RHS MSA with MPO connector
• Case operating temperature range:0°C to 70°C
• Power dissipation < 12 W
