Fiberworks 4ch. CWDM BiDi CATV Mux/Demux

Low Band, Mon. port, LC/APC, A-side

Varenr: F-CMUX-BIDI4LB-A-MLA
BeskrivelseTeknisk infoTilbehør
Beskrivelse
FEATURES
•  Coarse WDM in compliance with ITU-T G.694.2
•  4 bi-directional channels using standard 8-channel CWDM low band 1290 – 1430 nm, 20 nm spacing
•  2% monitoring port for Tx.
•  Based on thin film optics with epoxy free optical path
•  Protocol transparent (support 1G, 10G etc.)
•  Two modules fit in 1U in 19" rack
•  LC/APC connectors


Teknisk info

Produktinformasjon

Formfaktor Fiberworks
Linjefiber Enkel (bidi, mux/demux)
Antall kanaler 4
OADM Nei, mux/demux
Utvidelsesport Nei
Monitorport Ja (2%)
Konnektortype Vinklet (APC, for CATV)
Konnektor LC/APC
