Fiberworks 8+1 ch. CWDM Mux+Demux, LGX 3

C47-C61 + 1310nm/CWDM upgrade

Varenr: F-CMUX-8+1-4761-LGX3
Datablad / mer produktinformasjon
BeskrivelseTeknisk infoTilbehørAlternativer
Beskrivelse
FEATURES
- Coarse WDM in compliance with ITU-T G.694.2
- 8 CWDM channels 1470nm - 1610nm with 20nm spacing
- 1310nm wideband/upgrade port
- Based on thin film optics with epoxy free optical path
- Protocol transparent (support 1G, 10G etc.)
- Three modules fit in 1U in 19" rack
- With fastening screws
- LC/UPC connectors

Teknisk info

Produktinformasjon

Formfaktor LGX3
Fibertype SM
Linjefiber Dobbel (fiberpar, mux+demux)
Antall kanaler 8
OADM Nei, mux/demux
Konnektortype Rett (UPC, PC)
Konnektor LC/UPC
Andre egenskaper Utvidelsesport 1310 nm
