Fiberworks compact 8 ch. CWDM Mux/Demux

C27-C37 & C43-C45, 900µm pigtails

Varenr: F-CCMUX-8-2745-O9
BeskrivelseTeknisk info
Beskrivelse
FEATURES
•  Coarse WDM in compliance with ITU-T G.694.2
•  Standard 8 lowband CWDM channels 1270, 1290, 1310, 1330, 1350, 1370, 1430, 1450 nm

•  54 x 32 x 7.4 mm box
•  1m fibers, 900µm loose tube
•  Operating temperature: -40 ~ +80 °C
•  Based on free space optics with epoxy free optical path
•  Protocol transparent (support 1G, 10G etc.)


Teknisk info

Produktinformasjon

Formfaktor Minimodul
Fibertype SM
Linjefiber Enkel (bidi, mux/demux)
Antall kanaler 8
OADM Nei, mux/demux
Utvidelsesport Nei
Monitorport Nei
